Used Turbo Compact oven 2.5 mc
COD.1141
Dimensions
Useful volume m³ 0,6
External – encumbrance (w x d x h) mm 1720 x 2600 x 2400
Wall-to-Wall (w x d x h) mm 980 x 1400 x 1160
Useful (w x d x h) mm 615 x 111 x 1040
Mod.
Manufacturer JOB FORNI
Year of building 2000
Kiln weight kg 2.100
Feed
kiln Gas GPL
Electric Panel Volt 400
kW About 8
Insulation
Fiber with refractories Thickness 200 mm
Heating
Burners (80 kWt/cad) n. 2
Total installed power kWt 200
Air pre-heating no
Regulation Type Modulating valve with return on air and gas
Combustion fan power kW 1,2
Regulation zones n. 1
Max working temperature °C 1.200
Fireplaces n. 1
Dimensions mm 200 x 200
Thermocouple
Regulation TC n. 1 + 1 sicurezza
Thermocouple type S
Wagon with Vulkollan wheels
Internal n. 1
Total supplied n. 1
Loading platform height 530 mm
Flag door, manual opening, wheel closing n. 1
Control
Controller Mod. EL 496
