COD. 1120
Forno usato a gas, trattamento termico.
Doppia camera, in linea.
Ideale per cementazione, ricottura, distensione di particolare caricati su ceste.
Due porte verticali.
Dimensioni interne utili 800 x 1.000 x 800 mm ogni camera.
Carica 1.200 kg
Nr. 8 bruciatori recuperativi
Quadro elettrico obsoleto da revampare
Fabbricazione IPSEN
COD.1146
Manufacturer : Fibex
Dimensioni
strip useful width mm 200
Heating chamber lenght mm 2.500
Cooling chamber lenght mm 3.000
External furnace dimensions (L x P x H) mm 9.500 x 1.350 x 2.000
(indicative)
Heating data
type — electrical
Power feeding — 20 kW circa – 400 V 3PH
Max temperature °C 1150
Treating atmosphere — CH4 + aria
CH4 + air o Endogas
COD.1148
Dimensions
Volume m³ 3,5
Wall-to-Wall (w x d x h) mm 3.360 x 1.450 x 1.480
Useful dimensions (w x d x h) mm 3.100 x 1.000 x 1.120
External – encumbrance (w x d x h, indicative) mm 4.200 x 3.200 x 2.500
Manufacturer — JOB Forni
Heating
Burners ( 75.000 kCal/h) n. 9
Fuel – CH4
CH4
Total installed power kWt 600
Air pre-heating – sì
Regulation Type -Modulating valve with zero-governor
Regulation zones n. 1
Max working temperature °C 1.100
Electrical Panel Volt 400 kW Circa 5
COD.1132
Belt furnace for braze welding, used.
Mouth height: 200 mm
Belt width: 300 mm
Heating length: 2.900 = 5.400 mm
Cooling length: 5.000 mm with water jacket
Electric heaters
Maximum working temperature 1.200°C
Insulation in refractory bricks and rock wool
Treatment atmosphere: Hydrogen, Nitrogen or mixtures
Electric power heating, about 80 kW
COD.1129
Second hand Carriage gas furnace
Volume 3.5 cubic meters
Interior dimensions wall – wall (w x d x h): 1.310 x 3.370 x 1.350
Net internal dimensions – load (w x d x h) mm 910 x 3.170 x 1.150
SAFF manufacturer, year 1996
Natural gas supply
Fiber insulation with tiles, 200 mm thick
Heating: Nr. 6 Burners (80 kWt / each)
Total installed electrical power kWt 480
Regulation type: Modulating valve with return on air and gas
Control zones nr. 1
Max working temperature 1.100°C
Temperature sensor: Type K thermocouple
Trolleys with Vulkollan wheels inside the oven n. 1, Totals n. 3
Single-leaf manual door with leaflet closure
Ably TC 85 process controller
Safety thermoregulator n. 1
